9280 Gas Box
The 9280 Gas Box is an entry-level gas panel, optimised for John Crane's 2800E pump gas seal, for use in the chemical industry and general industry.
All the components are housed inside a lockable cabinet while allowing monitoring of the performance of the mechanical seal.
For high reliability sealing of volatile fluids in chemical and petrochemical processes.
Recommended for You
Features
- California Residents: PROPOSITION 65 WARNING
- Lockable cabinet prevents tampering of setpoints
- Mounted pressure gauge and flow indicators allow local monitoring of performance
- Can be supplied with a pressure switch and/or flow switch for remote monitoring
- Ensures a clean, dry and regulated supply of barrier gas to a gas-lubricated dual seal
- Allows reliable operation of a non-contacting, gas-lubricated seal to achieve high-reliability, zero-emission sealing of volatile or hazardous fluids
Parameters
- STANDARD MATERIALS
- Enclosure: Power coated steel
Connections: 316 stainless steel
Tubing: Nylon 11 - TEMPERATURE LIMITS
- Maximum Inlet Pressure: 12 barg (175 psig)
Maximum Outlet Pressure: 10 barg at 38°C (150 psig at 100°F)
7 barg at 50°C (100 psig at 120°F) - MAXIMUM FLOW
- 5 l/min (0.25 cubic foot/min)
- OPERATING FLOW
- 25 to 250 ml/min (1.5 to 15.2 cubic inch/min)
